Main Parameters

Unit

GRT50-2L

Max. Product Volume

(L)

2

Dry Cycle

(pcs/h)

1500

Screw Diameter

(mm)

50

Screw L/D Ratio

(L/D)

24

Screw Drive Power

(KW)

11

Screw heating Power

(3ΦKW)

4.2

Screw Heating Zone

(Zone)

3

HPDE Output

(kg/h)

35

Oil Pump Power

(KW)

5.5

Clamping Force

(KN)

40

Mold Stroke

(mm)

138-368

Max. Mold Size

(W×H)(mm)

300×320

Max. Die Diameter

(mm)

100

Die Heating Power

(4ΦKW)

1.8

NO. of Heating Zone

(Zone)

3

Blowing Pressure

(MPa)

0.6

Air Consumption

(M³/min)

0.4

Cooling Water Pressure

(MPa)

0.3

Water Consumption

(L/min)

35

Machine Size

(L×W×H)(m)

2.6×1.6×2.4

Machine Weight

(Ton)

3.2
